Angular position gauge

Range

0 – 360°

Case diameter

Ø 100 mm

Mounting hole & system

Ø101. Mounting brackets

Pointer

White

Dial

Black

Input

0,5 – 4,5V

Illumination

Red

Housing

Nylon PA66

Power supply

9/32 VDC

Power consumption

100 mA max + backlighting

Operating temperature

-20 +70 °C

Protection

IP67 on the front
