Advanced Hybrid CPU Dual Cortex A9 + FPGA, 1 GB RAM DDR3
128MB Flash + 16GB SD Card
8 x Analog inputs 0-300ohm
16 x Analog inputs 0-10V/4-20mA
8 x Analog inputs NTC 0-100Kohm with autorange
8 x Analog thermocouple inputs
6 x Analog inputs 0-36 V
3 x Frequency inputs W alternator / Pickup
8 x Digital inputs ON/OFF
8 x Relay outputs, single contact max 500mA
16 x Analog inputs 0-10V/4-20mA
8 x Analog inputs NTC 0-100Kohm with autorange
8 x Analog thermocouple inputs
6 x Analog inputs 0-36 V
3 x Frequency inputs W alternator / Pickup
8 x Digital inputs ON/OFF
8 x Relay outputs, single contact max 500mA
N.4 CAN Bus 2.0B
N.1 Ethernet 100M (protocols Modbus TCP e Nav)
N. 1 Wifi 802.11bgn
N. 1 USB OTG
N. 1 NMEA0183
N. 1 RS232
N.1 Ethernet 100M (protocols Modbus TCP e Nav)
N. 1 Wifi 802.11bgn
N. 1 USB OTG
N. 1 NMEA0183
N. 1 RS232
9-36V – 500mA average
220 x 143 x 77 mm
-20 +70 °C
IP65
